Basket Heaters

Basket heaters are a convenient option for heating materials without the need for a crucible. You can choose from a variety of sources based on the size and characteristics of your material or the form it is in. Some of these sources can be used multiple times to heat the same material. Just make sure to check the power requirements and shape of each source before you make your choice.

Please Select a Category:

Alumina Coated Baskets

Tungsten Baskets

Alumina Coated Baskets (1475°C)

Alumina Coated Baskets

#192: Dia.1mm/0.04″ Wire, 10.8mm/0.425″ Depth, 39 Amps, 272 Watts

Alumina Coated Basket Heaters

#193: Dia.0.5mm/0.02″ Wire, 5.7mm/0.225″ Depth, 11 Amps, 63 Watts

Alumina Coated Basket Heaters

#194: Dia.1.27mm/0.05″ Wire, 19.7mm/0.775″ Depth, 50 Amps, 350 Watts

Alumina Coated Basket Heaters

#195: Dia.1mm/0.04″ Wire, 18.4mm/0.725″ Depth, 33 Amps, 429 Watts

Alumina Coated Basket Heaters

4″ L X 1.125″ H X 0.900″ TID, 0.975″ INSIDE DEPTH, 0.050″ DIA WIRE

#196: 49 Amps, 768 Watts

Alumina Coated Basket Heaters

4″ L X 0.500″ H X 0.375″ TID, 0.350″ INSIDE DEPTH, 0.040″ DIA WIRE

#197: 40 Amps, 248 Watts

Tungsten Baskets (1800°C)

Tungsten Basket Heaters

#197: 1 Wire * Dia. 1.000mm/0.04″, 3.47Volt, 34 Amps, 118 Watts
#198: 3 Wires * Dia. 0.635mm/0.025″, 4.22Volt, 43 Amps, 181 Watts
#199: 3 Wires * Dia. 0.762mm/0.03″, 3.69Volt, 53 Amps, 196 Watts

Tungsten Basket Heaters

#200: 1 Wire * Dia. 1.000mm/0.04″, 3.04Volt, 36 Amps, 109 Watts
#201: 3 Wires * Dia. 0.635mm/0.025″, 3.5Volt, 44 Amps, 154 Watts
#202: 3 Wires * Dia. 0.762mm/0.03″, 3Volt, 54 Amps, 162 Watts

Tungsten Basket Heaters

#203: 1 Wire * Dia. 1.000mm/0.04″, 5.4Volt, 33 Amps, 178 Watts
#204: 3 Wires * Dia. 0.635mm/0.025″, 3.51Volt, 42 Amps, 147 Watts

Tungsten Basket Heaters

#205: 1 Wire * Dia. 1.53mm/0.06″, 4.02Volt, 59 Amps, 237 Watts
#206: 3 Wires * Dia. 0.76mm/0.03″, 5.83Volt, 52 Amps, 272 Watts

Tungsten Basket Heaters

#207: 1 Wire * Dia. 1.53mm/0.06″, 4.02Volt, 59 Amps, 237 Watts

#208: 3 Wires * Dia. 0.64mm/0.025″, 5.83Volt, 37 Amps, 216 Watts

Tungsten Basket Heaters

#209: 1 Wire * Dia. 1.000mm/0.04″, 6.62Volt, 32 Amps, 212 Watts
#210: 3 Wires * Dia. 0.635mm/0.025″, 7.04Volt, 39 Amps, 275 Watts

Tungsten Basket Heaters

#211: 1 Wire * Dia. 1.000mm/0.04″, 6.22Volt, 32 Amps, 199 Watts
#212: 3 Wires * Dia. 0.635mm/0.025″, 6.84Volt, 38 Amps, 260 Watts

Tungsten Basket Heaters

#213: 1 Wire * Dia. 1.000mm/0.04″, 5Volt, 37 Amps, 185 Watts #214: 3 Wires * Dia. 0.635mm/0.025″, 5.31Volt, 44 Amps, 234 Watts #215: 3 Wires * Dia. 1.00mm/0.04″, 4.8Volt, 55 Amps, 264 Watts

Tungsten Basket Heaters

#216: 1 Wire * Dia. 1.00mm/0.04″, 3.96Volt, 33 Amps, 131 Watts
#217: 1 Wire * Dia. 1.50mm/0.06″, 2.54Volt, 99 Amps, 251 Watts
#218: 3 Wires * Dia. 0.635mm/0.025″, 4.56Volt, 41 Amps, 187 Watts
#219: 3 Wires * Dia. 0.75mm/0.03″, 3.17Volt, 57 Amps, 181 Watts

Tungsten Basket Heaters

#220: 1 Wire * Dia. 1.000mm/0.04″, 3.22Volt, 37 Amps, 119 Watts
#221: 3 Wires * Dia. 0.635mm/0.025″, 4.04Volt, 45 Amps, 182 Watts
#222: 3 Wires * Dia. 0.75mm/0.03″, 3.36Volt, 57 Amps, 192 Watts

Tungsten Basket Heaters

#223: 1 Wire * Dia. 1.50mm/0.06″, 4.83Volt, 54 Amps, 261 Watts
#224: 3 Wires * Dia. 0.75mm/0.03″, 6.25Volt, 50 Amps, 312 Watts
#225: 4 Wires * Dia. 0.75mm/0.03″, 5.82Volt, 62 Amps, 361 Watts
