Thermal Filament Point Sources
Select a source that is suitable for the size and type of material you want to heat. Some sources can be used more than once to heat the same material. Make sure you check the power requirements and shape of each source before you choose one.
Tungsten Point Source (1800°C)
Double Loop Source Heaters
#158: 1 Wire * Dia. 1.524mm / 0.06″， 2.08 Volt, 73 Amps, 152 Watts
#159: 3 Wires * Dia. 0.635mm / 0.025″， 2.95 Volt, 50 Amps, 148 Watts
#160: 3 Wires * Dia. 0.762mm / 0.03″， 2.36 Volt, 65 Amps, 153 Watts
#161: 4 Wires * Dia. 0.762mm / 0.03″， 2.76 Volt, 80 Amps, 221 Watts
Double Loop Source Heaters
#162: 3 Wires * Dia. 0.762mm / 0.03″， 2.78 Volt, 69 Amps, 192 Watts
#163: 4 Wires * Dia. 0.762mm / 0.03″， 2.42 Volt, 87 Amps, 211 Watts
Single Loop Source Heaters
#164: 1 Wire * Dia. 1.524mm / 0.06″， 1.84 Volt, 75 Amps, 138 Watts
#165: 3 Wires * Dia. 0.635mm / 0.025″， 2.83 Volt, 48 Amps, 136 Watts
#166: 3 Wires * Dia. 0.762mm / 0.03″， 3.56 Volt, 78 Amps, 278 Watts
#167: 4 Wires * Dia. 0.762mm / 0.03″， 2.04 Volt, 82 Amps, 167 Watts
Single Loop Source Heaters
#168: 1 Wire * Dia. 1.00mm / 0.04″， 1.94 Volt, 42 Amps, 81 Watts
#169: 1 Wire * Dia. 1.524mm / 0.06″， 1.46 Volt, 75 Amps, 109 Watts
#170: 3 Wires * Dia. 0.635mm / 0.025″， 2.08 Volt, 51 Amps, 106 Watts
Point Source Heaters
#171: 1 Wire * Dia. 1.524mm / 0.06″， 1.39 Volt, 79 Amps, 110 Watts
#172: 3 Wires * Dia. 0.635mm / 0.025″， 2.26 Volt, 50 Amps, 113 Watts
#173: 3 Wires * Dia. 0.762mm / 0.03″， 1.94 Volt, 64 Amps, 124 Watts
#174: 4 Wires * Dia. 0.762mm / 0.03″， 1.59 Volt, 84 Amps, 134 Watts
Point Source Heaters
#175: 1 Wire * Dia. 1.524mm / 0.06″， 2.04 Volt, 74 Amps, 151 Watts
#176: 3 Wires * Dia. 0.635mm / 0.025″， 3.2 Volt, 51 Amps, 163 Watts
#177: 3 Wires * Dia. 0.762mm / 0.03″， 2.04 Volt, 64 Amps, 131 Watts
#178: 4 Wires * Dia. 0.762mm / 0.03″， 2.69 Volt, 80 Amps, 215 Watts
Point Source Heaters
#179: 1 Wire * Dia. 1.00mm / 0.04″， 3.44 Volt, 40 Amps, 138 Watts
#180: 1 Wire * Dia. 1.524mm / 0.06″， 3.09 Volt, 71 Amps, 219 Watts
#181: 3 Wires * Dia. 0.635mm / 0.025″， 3.8 Volt, 51 Amps, 194 Watts
#182: 3 Wires * Dia. 0.762mm / 0.03″， 3.5 Volt, 66 Amps, 231 Watts
#183: 4 Wires * Dia. 0.762mm / 0.03″， 3.13 Volt, 79 Amps, 247 Watts
