Buna-N (Nitrile) O-Rings (0.103 Section)

Buna-N (Nitrile) O-Rings (0.103 Section): Precision Sealing for Oil, Fuel, and Hydraulic Applications

Buna-N (Nitrile) O-Rings (0.103 section) from TFM are precision-engineered elastomeric seals crafted from 4900-70 grade nitrile rubber, designed to perform reliably in general-purpose applications involving petroleum-based fluids, gasoline, diesel, propane, and hydraulic oils. These O-rings are ideal for use in compact fittings, valves, and small component interfaces where sealing integrity is critical despite limited space.

With a 0.103-inch cross-sectional diameter, this size is optimized for sealing in tight or miniature assemblies, providing effective resistance to swelling, abrasion, and moderate temperatures.

Product Specifications:

Material Grade: 4900-70 Buna-N (Nitrile)
Color: Black
Durometer Hardness: 70 Shore A
Cross-Section Diameter: 0.103 inches
Temperature Range: –35°C to +110°C

Key Benefits:

Excellent compatibility with petroleum oils, gasoline, and hydraulic fluids
Compact sealing performance ideal for limited-space installations
Resistant to abrasion and compression set in static or light dynamic systems
Cost-efficient and widely available, suitable for general industrial use

Not Suitable For:

Automotive brake fluid, ozone, or prolonged UV exposure
Strong acids, ketones, or chlorinated solvents

Application Areas:

Miniature valves, fuel injection systems, and fluid couplings
Hydraulic tools and precision lubrication equipment
Oil-sealed instruments and low-pressure pneumatic assemblies
Compact mechanical seals in industrial or consumer-grade systems

TFM’s Buna-N (Nitrile) O-Rings (0.103 section) offer a dependable micro-sealing solution for petroleum-based fluids where space is limited and performance is non-negotiable.

Ordering Table

Drawing	Reference	O-Ring Size	O-Ring Material	O-Ring OD	O-Ring ID	O-Ring Cross Section	O-Ring Color	Part Number
	O-ring Seals, Nitrile (Buna-N)	102	4900-70 Nitrile	0.255	0.049	0.103	Black	O-B102
	O-ring Seals, Nitrile (Buna-N)	103	4900-70 Nitrile	0.287	0.081	0.103	Black	O-B103
	O-ring Seals, Nitrile (Buna-N)	104	4900-70 Nitrile	0.318	0.112	0.103	Black	O-B104
	O-ring Seals, Nitrile (Buna-N)	105	4900-70 Nitrile	0.349	0.143	0.103	Black	O-B105
	O-ring Seals, Nitrile (Buna-N)	106	4900-70 Nitrile	0.380	0.174	0.103	Black	O-B106
	O-ring Seals, Nitrile (Buna-N)	107	4900-70 Nitrile	0.412	0.206	0.103	Black	O-B107
	O-ring Seals, Nitrile (Buna-N)	108	4900-70 Nitrile	0.443	0.237	0.103	Black	O-B108
	O-ring Seals, Nitrile (Buna-N)	109	4900-70 Nitrile	0.505	0.299	0.103	Black	O-B109
	O-ring Seals, Nitrile (Buna-N)	110	4900-70 Nitrile	0.568	0.362	0.103	Black	O-B110
	O-ring Seals, Nitrile (Buna-N)	111	4900-70 Nitrile	0.630	0.424	0.103	Black	O-B111
	O-ring Seals, Nitrile (Buna-N)	112	4900-70 Nitrile	0.693	0.487	0.103	Black	O-B112
	O-ring Seals, Nitrile (Buna-N)	113	4900-70 Nitrile	0.755	0.549	0.103	Black	O-B113
	O-ring Seals, Nitrile (Buna-N)	114	4900-70 Nitrile	0.818	0.612	0.103	Black	O-B114
	O-ring Seals, Nitrile (Buna-N)	115	4900-70 Nitrile	0.880	0.674	0.103	Black	O-B115
	O-ring Seals, Nitrile (Buna-N)	116	4900-70 Nitrile	0.943	0.737	0.103	Black	O-B116
	O-ring Seals, Nitrile (Buna-N)	117	4900-70 Nitrile	1.005	0.799	0.103	Black	O-B117
	O-ring Seals, Nitrile (Buna-N)	118	4900-70 Nitrile	1.068	0.862	0.103	Black	O-B118
	O-ring Seals, Nitrile (Buna-N)	119	4900-70 Nitrile	1.130	0.924	0.103	Black	O-B119
	O-ring Seals, Nitrile (Buna-N)	120	4900-70 Nitrile	1.193	0.987	0.103	Black	O-B120
	O-ring Seals, Nitrile (Buna-N)	121	4900-70 Nitrile	1.255	1.049	0.103	Black	O-B121
	O-ring Seals, Nitrile (Buna-N)	122	4900-70 Nitrile	1.318	1.112	0.103	Black	O-B122
	O-ring Seals, Nitrile (Buna-N)	123	4900-70 Nitrile	1.380	1.174	0.103	Black	O-B123
	O-ring Seals, Nitrile (Buna-N)	124	4900-70 Nitrile	1.443	1.237	0.103	Black	O-B124
	O-ring Seals, Nitrile (Buna-N)	125	4900-70 Nitrile	1.505	1.299	0.103	Black	O-B125
	O-ring Seals, Nitrile (Buna-N)	126	4900-70 Nitrile	1.568	1.362	0.103	Black	O-B126
	O-ring Seals, Nitrile (Buna-N)	127	4900-70 Nitrile	1.630	1.424	0.103	Black	O-B127
	O-ring Seals, Nitrile (Buna-N)	128	4900-70 Nitrile	1.693	1.487	0.103	Black	O-B128
	O-ring Seals, Nitrile (Buna-N)	129	4900-70 Nitrile	1.755	1.549	0.103	Black	O-B129
	O-ring Seals, Nitrile (Buna-N)	130	4900-70 Nitrile	1.818	1.612	0.103	Black	O-B130
	O-ring Seals, Nitrile (Buna-N)	131	4900-70 Nitrile	1.880	1.674	0.103	Black	O-B131
	O-ring Seals, Nitrile (Buna-N)	132	4900-70 Nitrile	1.943	1.737	0.103	Black	O-B132
	O-ring Seals, Nitrile (Buna-N)	133	4900-70 Nitrile	2.005	1.799	0.103	Black	O-B133
	O-ring Seals, Nitrile (Buna-N)	134	4900-70 Nitrile	2.068	1.862	0.103	Black	O-B134
	O-ring Seals, Nitrile (Buna-N)	135	4900-70 Nitrile	2.131	1.925	0.103	Black	O-B135
	O-ring Seals, Nitrile (Buna-N)	136	4900-70 Nitrile	2.193	1.987	0.103	Black	O-B136
	O-ring Seals, Nitrile (Buna-N)	137	4900-70 Nitrile	2.256	2.050	0.103	Black	O-B137
	O-ring Seals, Nitrile (Buna-N)	138	4900-70 Nitrile	2.318	2.112	0.103	Black	O-B138
	O-ring Seals, Nitrile (Buna-N)	139	4900-70 Nitrile	2.381	2.175	0.103	Black	O-B139
	O-ring Seals, Nitrile (Buna-N)	140	4900-70 Nitrile	2.443	2.237	0.103	Black	O-B140
	O-ring Seals, Nitrile (Buna-N)	141	4900-70 Nitrile	2.506	2.300	0.103	Black	O-B141
	O-ring Seals, Nitrile (Buna-N)	142	4900-70 Nitrile	2.568	2.362	0.103	Black	O-B142
	O-ring Seals, Nitrile (Buna-N)	143	4900-70 Nitrile	2.631	2.425	0.103	Black	O-B143
	O-ring Seals, Nitrile (Buna-N)	144	4900-70 Nitrile	2.693	2.487	0.103	Black	O-B144
	O-ring Seals, Nitrile (Buna-N)	145	4900-70 Nitrile	2.756	2.550	0.103	Black	O-B145
	O-ring Seals, Nitrile (Buna-N)	146	4900-70 Nitrile	2.818	2.612	0.103	Black	O-B146
	O-ring Seals, Nitrile (Buna-N)	147	4900-70 Nitrile	2.881	2.675	0.103	Black	O-B147
	O-ring Seals, Nitrile (Buna-N)	148	4900-70 Nitrile	2.943	2.737	0.103	Black	O-B148
	O-ring Seals, Nitrile (Buna-N)	149	4900-70 Nitrile	3.006	2.800	0.103	Black	O-B149
	O-ring Seals, Nitrile (Buna-N)	150	4900-70 Nitrile	3.068	2.862	0.103	Black	O-B150
	O-ring Seals, Nitrile (Buna-N)	151	4900-70 Nitrile	3.193	2.987	0.103	Black	O-B151
	O-ring Seals, Nitrile (Buna-N)	152	4900-70 Nitrile	3.443	3.237	0.103	Black	O-B152
	O-ring Seals, Nitrile (Buna-N)	153	4900-70 Nitrile	3.693	3.487	0.103	Black	O-B153
	O-ring Seals, Nitrile (Buna-N)	154	4900-70 Nitrile	3.943	3.737	0.103	Black	O-B154
	O-ring Seals, Nitrile (Buna-N)	155	4900-70 Nitrile	4.193	3.987	0.103	Black	O-B155
	O-ring Seals, Nitrile (Buna-N)	156	4900-70 Nitrile	4.443	4.237	0.103	Black	O-B156
	O-ring Seals, Nitrile (Buna-N)	157	4900-70 Nitrile	4.693	4.487	0.103	Black	O-B157
	O-ring Seals, Nitrile (Buna-N)	158	4900-70 Nitrile	4.943	4.737	0.103	Black	O-B158
	O-ring Seals, Nitrile (Buna-N)	159	4900-70 Nitrile	5.193	4.987	0.103	Black	O-B159
	O-ring Seals, Nitrile (Buna-N)	160	4900-70 Nitrile	5.443	5.237	0.103	Black	O-B160
	O-ring Seals, Nitrile (Buna-N)	161	4900-70 Nitrile	5.693	5.487	0.103	Black	O-B161
	O-ring Seals, Nitrile (Buna-N)	162	4900-70 Nitrile	5.943	5.737	0.103	Black	O-B162
	O-ring Seals, Nitrile (Buna-N)	163	4900-70 Nitrile	6.193	5.987	0.103	Black	O-B163
	O-ring Seals, Nitrile (Buna-N)	164	4900-70 Nitrile	6.443	6.237	0.103	Black	O-B164
	O-ring Seals, Nitrile (Buna-N)	165	4900-70 Nitrile	6.693	6.487	0.103	Black	O-B165
	O-ring Seals, Nitrile (Buna-N)	166	4900-70 Nitrile	6.943	6.737	0.103	Black	O-B166
	O-ring Seals, Nitrile (Buna-N)	167	4900-70 Nitrile	7.193	6.987	0.103	Black	O-B167
	O-ring Seals, Nitrile (Buna-N)	168	4900-70 Nitrile	7.443	7.237	0.103	Black	O-B168
	O-ring Seals, Nitrile (Buna-N)	169	4900-70 Nitrile	7.693	7.487	0.103	Black	O-B169
	O-ring Seals, Nitrile (Buna-N)	170	4900-70 Nitrile	7.943	7.737	0.103	Black	O-B170
	O-ring Seals, Nitrile (Buna-N)	171	4900-70 Nitrile	8.193	7.987	0.103	Black	O-B171
	O-ring Seals, Nitrile (Buna-N)	172	4900-70 Nitrile	8.443	8.237	0.103	Black	O-B172
	O-ring Seals, Nitrile (Buna-N)	173	4900-70 Nitrile	8.693	8.487	0.103	Black	O-B173
	O-ring Seals, Nitrile (Buna-N)	174	4900-70 Nitrile	8.943	8.737	0.103	Black	O-B174
	O-ring Seals, Nitrile (Buna-N)	175	4900-70 Nitrile	9.193	8.987	0.103	Black	O-B175
	O-ring Seals, Nitrile (Buna-N)	176	4900-70 Nitrile	9.443	9.237	0.103	Black	O-B176
	O-ring Seals, Nitrile (Buna-N)	177	4900-70 Nitrile	9.693	9.487	0.103	Black	O-B177
	O-ring Seals, Nitrile (Buna-N)	178	4900-70 Nitrile	9.943	9.737	0.103	Black	O-B178
