Zero-Length Reducer ConFlat® (CF) UHV Flanges (Standard)

Reducer Flange Characteristics

When adapting knife-edge flanges of varying sizes, it’s essential to understand their unique features:

  • Bolt Hole Design: Smaller flanges typically come with blind tapped bolt holes, while larger flanges often incorporate through-holes. In instances where the diameters of the two flanges are similar, both flanges will be tapped.
  • Part Numbering: Any part number that concludes with the letter “T” indicates that the flange is a double-tapped variant, ensuring additional fastening options.

Ordering Table

Flange Size/OD Note Part Number
DN200CF (10.00" OD) — RF1000X133
DN200CF (10.00" OD) — RF1000X212
DN200CF (10.00" OD) — RF1000X275
DN200CF (10.00" OD) — RF1000X337
DN200CF (10.00" OD) — RF1000X450
DN200CF (10.00" OD) — RF1000X462
DN200CF (10.00" OD) — RF1000X600
DN200CF (10.00" OD) — RF1000X800
DN275CF (13.25" OD) — RF1325X1000
DN275CF (13.25" OD) — RF1325X133
DN275CF (13.25" OD) — RF1325X212
DN275CF (13.25" OD) — RF1325X275
DN275CF (13.25" OD) — RF1325X337
DN275CF (13.25" OD) — RF1325X450
DN275CF (13.25" OD) — RF1325X462
DN275CF (13.25" OD) — RF1325X600
DN275CF (13.25" OD) — RF1325X800
DN25CF (2.13" OD) — RF212X133T
DN35CF-DN40CF (2.75" OD) — RF275X133
DN35CF-DN40CF (2.75" OD) — RF275X212T
DN50CF (3.38" OD) — RF337X133
DN50CF (3.38" OD) — RF337X212T
DN50CF (3.38" OD) — RF337X275T
DN63CF (4.50" OD) — RF450X133
DN63CF (4.50" OD) — RF450X212
DN63CF (4.50" OD) — RF450X275
DN63CF (4.50" OD) — RF450X337T
DN75CF (4.63" OD) — RF462X133
DN75CF (4.63" OD) — RF462X212
DN75CF (4.63" OD) — RF462X275
DN75CF (4.63" OD) — RF462X337
DN100CF (6.00" OD) — RF600X133
DN100CF (6.00" OD) — RF600X212
DN100CF (6.00" OD) — RF600X275
DN100CF (6.00" OD) — RF600X337
DN100CF (6.00" OD) — RF600X450
DN100CF (6.00" OD) 1 RF600X462
DN125CF (6.75" OD) — RF675X133
DN125CF (6.75" OD) — RF675X212
DN125CF (6.75" OD) — RF675X275
DN125CF (6.75" OD) — RF675X337
DN125CF (6.75" OD) — RF675X450
DN125CF (6.75" OD) — RF675X462
DN125CF (6.75" OD) — RF675X600T
DN160CF (8.00" OD) — RF800X133
DN160CF (8.00" OD) — RF800X212
DN160CF (8.00" OD) — RF800X275
DN160CF (8.00" OD) — RF800X337
DN160CF (8.00" OD) — RF800X450
DN160CF (8.00" OD) — RF800X462
DN160CF (8.00" OD) — RF800X600
DN250CF (12.00" OD) — RF1200X1000
