ISO200 HV Flanges

The ISO flange, also known as Large ISO, is a trusted solution for high-vacuum (HV) chamber ports. TFM’s ISO200 HV Flanges are designed for durability and reliability, catering to the precise needs of HV systems.

Available Styles:

  • ISO-K: Utilizes clamp fasteners for quick and efficient assembly.
  • ISO-F: Employs nut and bolt fasteners for robust, long-term connections.

Mixed Connection Flexibility:

ISO200 HV Flanges support mixed ISO-K and ISO-F joints, facilitated by various bolt and clamp options to enhance system adaptability.

Sealing and Alignment:

ISO flanges share the same design principles as KF seals:

  • Each flange face is counter-bored or grooved to accommodate a metal centering ring with an elastomeric o-ring around its outer diameter.
  • The centering ring aligns the flanges and securely holds the o-ring, ensuring consistent and reliable sealing.

Operational Parameters:

  • Temperature Range: ~0°C to 120–180°C, depending on o-ring material.
  • Pressure Range: From atmosphere to ~10⁻⁸ torr or mbar.

TFM’s ISO200 HV Flanges are engineered for high performance and reliability in challenging vacuum environments. Contact us for standard or customized flange solutions tailored to your requirements!

Ordering Table

Flange Size/OD Type Flange Material Drawing Nominal Tube OD Bore Counter Bore Thickness Bolt Circle Dia. Bolt Hole Dia. # of Bolt Holes Minimal Number of Clamps Part Number
ISO200-F (11.22" OD) Blank, Bolt Style 6061-T6 Aluminum Tooltip 8 — — 0.63 10.236 0.433 12 — QF200-ABF
ISO200-F (11.22" OD) Blank, Bolt Style 304L SS Tooltip 8 — — 0.63 10.236 0.433 12 — QF200-BF
ISO200-F (11.22" OD) Bored, Bolt Style 304L SS Tooltip 8 7.88 8.020 0.63 10.236 0.433 12 — QF200-SWF
ISO200-F (11.22" OD) Bored, Bolt Style 316L SS Tooltip — 8.386 8.640 0.63 10.236 0.433 12 — QF200-SWF-M
ISO200-K (9.45" OD) Blank, Clamp Style 6061-T6 Aluminum Tooltip 8 — — 0.47 — — — 6 QF200-ABK
ISO200-K (9.45" OD) Bored, Clamp Style 316L SS Tooltip — 8.386 8.640 0.47 — — — 6 QF200-SWK-M
ISO200-K (9.45" OD) Blank, Clamp Style 304L SS Tooltip 8 — — 0.47 — — — 6 QF200-BK
ISO200-K (9.45" OD) Bored, Clamp Style 304L SS Tooltip 8 7.88 8.020 0.47 — — — 6 QF200-SWK
