ISO630 HV Flanges

ISO630 HV Flanges

ISO630 HV Flanges are designed for high vacuum (HV) and ultra-high vacuum (UHV) applications, offering a reliable sealing solution for large-diameter vacuum systems. These flanges conform to ISO standards, ensuring compatibility with a wide range of vacuum components.

Key Features

  • Material: Manufactured from high-quality stainless steel (304L or 316L) for excellent corrosion resistance and durability.

  • Vacuum Compatibility: Designed for HV and UHV applications, with minimal leakage and high mechanical stability.

  • Sealing Method: Utilizes O-ring seals with a clamping or bolted connection, ensuring a tight and secure vacuum seal.

  • Flange Sizes: Available in ISO630 and other standard sizes for different vacuum system configurations.

  • Mounting Options: Compatible with both clamp-type (ISO-K) and bolt-type (ISO-F) mounting systems.

Applications

  • Vacuum Chambers: Used in research, industrial, and scientific vacuum systems.

  • Thin Film Deposition: Ideal for PVD, CVD, and sputtering systems in semiconductor and materials science applications.

  • High Energy Physics: Utilized in particle accelerators, fusion research, and space simulation chambers.

  • Analytical Instruments: Common in mass spectrometry, electron microscopy, and surface analysis equipment.

Why Choose TFM’s ISO630 HV Flanges?

  • Precision Machining: Ensures leak-tight connections and high vacuum performance.

  • Standard Compliance: Fully compatible with ISO-K and ISO-F vacuum components.

  • Durability: Designed for long-term use in demanding vacuum environments.

Ordering Table

Flange Size/OD Type Flange Material Drawing Nominal Tube OD Bore Counter Bore Thickness Bolt Circle Dia. Bolt Hole Dia. # of Bolt Holes Part Number
ISO630-F (29.53" OD) Blank, Bolt Style 6061-T6 Aluminum Tooltip 26 — — 0.94 28.350 0.550 20 QF630-ABF
ISO630-F (29.53" OD) Bored, Bolt Style 316L SS Tooltip 26 25.630 26.020 0.94 28.350 0.550 20 QF630-SWF-M
ISO630-F (29.53" OD) Bored, Bolt Style 304L SS Tooltip 24 23.81 24.020 0.94 28.350 0.550 20 QF630-SWF
ISO630-F (29.53" OD) Blank, Bolt Style 304L SS Tooltip 26 — — 0.94 28.350 0.550 20 QF630-BF
ISO630-K (27.17" OD) Bored, Clamp Style 304L SS Tooltip 24 23.81 24.020 0.87 — — — QF630-SWK
ISO630-K (27.17" OD) Blank, Clamp Style 304L SS Tooltip 24 — — 0.86 — — — QF630-BK
ISO630-K (27.17" OD) Blank, Clamp Style 6061-T6 Aluminum Tooltip 24 — — 0.87 — — — QF630-ABK
ISO630-K (27.17" OD) Bored, Clamp Style 316L SS Tooltip 26 25.630 26.020 0.87 — — — QF630-SWK-M
