Tungsten Oxide Sputtering Target, WO3

Chemical Formula: WO3
Catalog Number: TFM-SPT-0641
CAS Number: 1314-35-8
Purity: 99.9%
Shape: Discs, Plates, Column Targets, Step Targets, Custom-made

Tungsten Oxide  sputtering target  come in various forms, purities, sizes, and prices. Thin Film Materials (TFM) manufactures and supplies top-quality sputtering targets at competitive prices.

Product Overview

Tungsten Oxide Sputtering Target (WO3) is a ceramic sputtering target used to deposit composition-specific oxide thin films. Compared with metallic targets, oxide targets are typically more sensitive to density, porosity, brittleness, thermal shock, and bonding design. In practice, target microstructure, thickness, cooling conditions, and the chosen sputtering mode can all affect arc stability, particle generation, and deposited-film performance.

Material and Deposition Characteristics

RF magnetron sputtering is commonly considered for insulating or semiconducting oxide targets, while sufficiently conductive formulations may allow alternative power modes in some systems. Target density and microstructural uniformity matter because pores, cracks, and local inhomogeneities can contribute to unstable plasma, particles, or target damage. For brittle ceramics, bonded assemblies and gradual power ramping are often worth evaluating.

Technical Data

ParameterTypical Value / RangeImportance
MaterialTungsten Oxide (WO₃ / WOₓ)Functional oxide ceramic
Purity99.9% – 99.99%Impacts optical & electrical performance
Target FormDisc / Plate (bonded or unbonded)Compatible with sputtering systems
Diameter25 – 300 mm (custom)Fits standard magnetron cathodes
Thickness3 – 6 mm (typical)Influences target lifetime
Sputtering ModeRF magnetron sputteringRequired for insulating oxides
Backing PlateCopper / Titanium (optional)Improves thermal management
MaterialKey AdvantageTypical Application
Tungsten Oxide (WO₃)Electrochromic & optical functionalitySmart windows & sensors
Molybdenum Oxide (MoO₃)High work functionElectronics & optics
Vanadium Oxide (VO₂)Thermochromic behaviorSmart coatings
QuestionAnswer
Is RF sputtering required for tungsten oxide targets?Yes, RF magnetron sputtering is typically used for WO₃ targets.
Can the stoichiometry be customized?Yes, WO₃ or sub-stoichiometric WOₓ compositions can be supplied.
Are bonded targets available?Yes, copper- or titanium-backed targets are available upon request.
Can large-area targets be produced?Yes, targets up to 300 mm or larger can be manufactured.
Is a Certificate of Analysis provided?Yes, CoA is available upon request.

Typical Thin-Film Applications

  • Dielectric, insulating, optical, magnetic, protective, or functional ceramic thin films
  • Semiconductor, sensor, photonic, and multilayer coating research
  • Applications where oxide composition, density, and process stability affect film performance

Target Configuration and Ordering Considerations

When requesting a quotation, provide target diameter or rectangular dimensions, thickness, purity or composition, required quantity, and whether a backing plate or bonded assembly is needed. For brittle ceramic or compound targets, it is useful to specify the cathode model, backing-plate material, preferred bonding method, operating power if known, and any density, tolerance, or inspection-document requirements. TFM can review drawings, old-target photos, and application details when custom dimensions are required.

Frequently Asked Questions

Is Tungsten Oxide better suited to RF or DC sputtering?

RF magnetron sputtering is commonly considered for insulating or semiconducting oxide targets. If a specific formulation is sufficiently conductive, other modes may also be possible, but the equipment and target properties should be confirmed.

Why is density important for a Tungsten Oxide target?

Density and microstructural uniformity affect erosion stability, thermal behavior, and particle risk. Pores, cracks, or local density variations can contribute to unstable sputtering and target damage.

Should a Tungsten Oxide target be bonded to a backing plate?

Bonding is often useful for brittle oxide targets because it can improve mechanical support and heat transfer. The backing material and bonding method should be chosen according to target size, thickness, and operating conditions.

Will the deposited film always have the same composition as WO3?

Not always. Film composition can be affected by preferential sputtering, reactive gas, substrate temperature, re-sputtering, and chamber conditions. Composition-sensitive films should be verified after deposition.

How should power be ramped on a brittle Tungsten Oxide target?

A conservative power ramp and stable cooling are generally advisable. The exact operating procedure should follow the target size, bonding condition, cathode design, and supplier recommendations rather than a universal wattage.

What information should I provide when ordering Tungsten Oxide?

Provide formula or composition, purity, dimensions, quantity, backing and bonding requirements, cathode model or drawing, and any density, tolerance, or inspection requirements.

Order Now

WO₃ Target ≥99.5% ø50.8*3.18mm Indium Bonded to 2.0mm Cu B/Plate, WO3 target 3N/4N ø50.8×6.35mm, Ø2" × 3.18 mm, Tungsten Oxide (WO₃), 2N5, Bonded to 2 mm Cu B/P

Reviews

There are no reviews yet.

Be the first to review “Tungsten Oxide Sputtering Target, WO3”

Your email address will not be published. Required fields are marked *

Related Products

Related products

FAQ

It’s the source material (in solid form) used in sputter deposition to eject atoms or molecules that then form a thin film on a substrate.

Targets can be pure metals (e.g., gold, copper, aluminum), ceramics (e.g., Al₂O₃, SiO₂, TiO₂), alloys, or composites—chosen based on the film’s desired properties.



They are produced by processes such as melting/casting for metals or sintering (often with hot isostatic pressing) for ceramics and composite targets to ensure high density and purity.



In a vacuum chamber, a plasma (typically argon) bombards the target, ejecting atoms that travel and condense on a substrate, forming a thin film.



Key factors include the target’s purity, density, grain structure, and the sputtering yield (i.e. how many atoms are ejected per incident ion), as well as operating conditions like power density and gas pressure.



Operators monitor target erosion (often by measuring the depth of the eroded “race track”) or track total energy delivered (kilowatt-hours) until it reaches a threshold that can compromise film quality.



Fragile materials (such as many ceramics or certain oxides) and precious metals often require a backing plate to improve cooling, mechanical stability, and to allow thinner targets that reduce material costs.



DC sputtering is used for conductive targets, while RF sputtering is necessary for insulating targets (like many oxides) because it prevents charge buildup on the target’s surface.



In reactive sputtering, a reactive gas (e.g., oxygen or nitrogen) is introduced to form compound films on the substrate, but it may also “poison” the target surface if not carefully controlled.



Many manufacturers prefer to control raw material quality by sourcing their own powders; using external powders can risk impurities and inconsistent target properties.



Targets should be stored in clean, dry conditions (often in original packaging or re-wrapped in protective materials) and handled with gloves to avoid contamination, ensuring optimal performance during deposition.

Deposition rate depends on factors such as target material and composition, power density, working gas pressure, substrate distance, and the configuration of the sputtering system (e.g., magnetron design).
